1-Channel General Purpose Drop Over (1.25") Linebacker

  • Protects cables and hoses up to 1.25" outside dia.
  • Patented T-Connectors to extend to any length
  • Drop-over model
  • All-weather polyurethane construction
  • Modular interlocking design is lightweight and easy to transport, setup, disassemble, and store
  • Quick solution to protect single runs of cable and hose lines
  Checkers

HEAVY DUTY LINEBACKER

LINEBACKER® 1-CHANNEL DROP OVER CABLE PROTECTOR offers a quick solution to protect minimal runs of cable and hose lines. These models provide solutions for heavy duty, high load bearing operations as well as lighter duty, general purpose needs for cables up to 1.6" high and 1.25" wide.


CP1X125-GP-DO — SPECIFICATIONS

Load Capacity

Max load tested at 21oC
5,307 kg / Tire
10,614 kg / Axle


A. Length: (91,44 cm)
B. Width: (29,21 cm)
C. Height: (4,06 cm)
D. Channel width: (8,26 cm)
E. Channel height: (3,18 cm)
F. Weight: (13,0 kg)


Specyfication data

1-Channel General Purpose Drop Over (1.25


LOAD CAPACITY — Max load tested at 70°F (21° C)
11,700 lb./Tire (5,307 kg) 23,400 lb./Axle (10,614 kg)

COLOR OPTIONS

  • Orange
  • Black
  • Yellow
